Διαθέσιμο
Κωδικός
0.501.494
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 - 295 Vac (145 - 295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz + - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 - 7 ms, 10 ms max.
DC voltage
12 V
Configuration
12 V / 7 Ah x 1
Recharge time
6 - 8 h
USB (optional)
Supports Windows 98 / 2000 / 2003 / XP / Vista / 2008 / Windows?7 / 8 / 10
Protections
Short circuit - battery overcharge , overdischarge , overload - surge
Humidity
20 - 90% RH @ 0- 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Plastic Case
Net / Gross weight (kg) 4.2 / 4.6, Dimensions 90 x 305 x 165, Packaged dimensions: 133 x 349 x 232, Quantity /20ft 2300 pcs

Διαθέσιμο
Κωδικός
0.502.038
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 -295 Vac (145 -295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz+ - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 -7 ms, 10 ms max.
DC voltage
12 V
Configuration
12 V / 7 Ah x 1
Recharge time
6 - 8 h
USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows?7 / 8 / 10
Protections
hort circuit - battery overcharge - overdischarge - overload - surge
Humidity
20 -90% RH @ 0 - 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Plastic Case
Net / Gross weight (kg) 4.2 / 4.6, Dimensions 90 Χ 305 Χ 165, Packaged dimensions: 133 x 349 x 232, Quantity /20ft 2300 pcs

Διαθέσιμο
Κωδικός
0.502.272
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 -295 Vac (145 -295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz+ - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 -7 ms, 10 ms max.
DC voltage
12 V
Configuration
12 V / 9 Ah x 1
Recharge time
6 - 8 h
USB (optional)
Supports Windows 98 / 2000 / 2003 / XP / Vista / 2008 / Windows7 / 8 / 10
Protections
hort circuit - battery overcharge - overdischarge - overload - surge
Humidity
20 -90% RH @ 0 - 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Plastic Case
Net / Gross weight (kg) 5.0 / 5.4, Dimensions 90 Χ 305 Χ 165, Packaged dimensions: 133 x 349 x 232, Quantity /20ft 2300 pcs

Διαθέσιμο
Κωδικός
0.501.495
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 - 295 Vac (145 - 295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz + - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 - 7 ms, 10 ms max.
DC voltage
12 V
Configuration
12 V / 9 Ah x 1
Recharge time
6 - 8 h
USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows?7 / 8 / 10
Protections
Short circuit - battery overcharge - overdischarge - overload - surge
Humidity
20 - 90% RH @ 0- 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Plastic Case
Net / Gross weight (kg) 5.0 / 5.4, Dimensions 90 ? 305 ? 165, Packaged dimensions: 133 x 349 x 232, Quantity /20ft 2300 pcs

Διαθέσιμο
Κωδικός
0.502.039
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 - 295 Vac (145 - 295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz + - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 - 7 ms, 10 ms max.
DC voltage
24 V
Configuration
12 V / 7 Ah x 2
Recharge time
6 - 8 h
USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows?7 / 8 / 10
Protections
Short circuit - battery overcharge - overdischarge - overload - surge
Humidity
20 - 90% RH @ 0- 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Plastic Case
Net / Gross weight (kg) 9.4 / 9.9, Dimensions 115 x 320 x 220, Packaged dimensions: 161 x 369 x 290, Quantity /20ft 1400 pcs

Διαθέσιμο
Κωδικός
0.500.950
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 - 295 Vac (145 - 295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz + - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 - 7 ms, 10 ms max.
DC voltage
24 V
Configuration
12 V / 9 Ah x 2
Recharge time
6 - 8 h
USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows?7 / 8 / 10
Protections
Short circuit - battery overcharge - overdischarge - overload - surge
Humidity
20 - 90% RH @ 0- 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Plastic Case
Net / Gross weight (kg) 9.8 / 10.3, Dimensions 115 x 320 x 220, Packaged dimensions: 161 x 369 x 290, Quantity /20ft 1400 pcs

Περιορισμένα τεμάχια
Κωδικός
0.502.475
Κατηγορία
Tescom UPS
Voltage
110/120 VAC or 220/230/240 VAC
Voltage Range
81-145 VAC / 162-290 VAC
Frequency Range
60/50 Hz (auto sensing)
Power Factor
0,6
Voltage
110/120 VAC or 220/230/240 VAC
AC Voltage Regulation (Batt. Mode)
+- 10
Frequency Range
60 Hz or 50 Hz ±1 Hz
Waveform
Simulated Sinewave
Transfer time
Typical 2 -6ms
Outlets
4 x Schuko
Battery Type & Number
12 V/9 Ah x 2
Typical Recharge Time
4-6 hours recover to 90% capacity
Battery Mode
Sounding every 10 seconds
Low Battery
Sounding every second
Overload
Sounding every 0.5 second
Fault
Continuously sounding
Protections
Overload, discharge, and overcharge protection
Dimension
2320 x 130 x 182
Net Weight
11 kg
Humidity
0-90 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 40dB
Optional USB / RS232 Port
Supports: Windows? 2000/XP/Vista/7/8/10, Linux, Unix, Mac OS

Διαθέσιμο
Κωδικός
0.500.869
Κατηγορία
Tescom UPS
Voltage
100 / 110 / 120 V: 80 - 150 Vac, 220 / 230 / 240 V: 162 - 295 Vac (145 - 295 Vac optional)
Frequency
50 / 60 Hz + - 10% (auto-sensing)
Voltage
100 / 110 / 120 Vac + - 10% or 220 / 230 / 240 Vac + - 10%
Frequency
50 / 60 Hz + - 1% (auto-sensing)
Waveform
Mains mode: pure sine wave Battery mode: simulated sine wave
Transfer time
Typical 2 - 7 ms, 10 ms max.
DC voltage
24 V
Configuration
12 V / 9 Ah x 2
Recharge time
6 - 8 h
USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows?7 / 8 / 10
Protections
Short circuit - battery overcharge - overdischarge - overload - surge
Humidity
20 - 90% RH @ 0- 40 (non-condensing)
Noise level
<= 40 dB (1 m)
Metal Case
Net / Gross weight (kg) 12.9 / 13.3, Dimensions 25 x 380 x 225, Packaged dimensions: 161 x 369 x 290, Quantity /20ft 1000 pcs

Διαθέσιμο
Κωδικός
0.502.040
Κατηγορία
Tescom UPS
Rated voltage
208 V / 220 V / 230 V / 240 Vac
Voltage range
110 - 176 Vac (linear derating between 50% and 100% load ), 176 - 280 Vac (no derating), 280 - 300 Vac (derating 50%)
Frequency
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
25% +15% (settable)Total Harmonic Distortion (THDi) <= 6%
Voltage
208 V / 220 V / 230 V / 240 Vac (settable via LCD)
Voltage regulation
1 +-
Waveform
Sinusoidal
Crest factor
<= 2% (linear load); <= 5% (non-linear load)
Transfer time
Mains mode to battery mode: 0 ms, Inverter mode to bypass mode: 4 ms (typical)
Overload capability
105% - 125%: transfer to bypass in 1 min, 125% - 150%: transfer to bypass in 30 s, > 150%: transfer to bypass in 300 ms
Mains mode
>= 90%
Battery mode
>= 85%
ECO mode
>= 95%
DC voltage
24 V
Inbuilt battery
2 x12v 9Ah
Charging current (max.)
1A
Recharge time
8 h
TYPE
VRLA sealed lead acid maintenance free
ALARMS
On Utility failure / Low battery / Overload / UPS fault
RS232 (standard) / USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows? 7 / 8 / 10
SNMP (optional)
Power management from SNMP manager and web browser
Output Power Plugs
2 Schuko (3 IEC optional)
Operating temperature
0 - 40
Storage temperature
from -40 to 70 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000m, derating 1% for each additional 100m
IP rating
IP20
Noise level
<= 50 dB (1m)
Dimensions
144x336x214
Packaged dimensions
232x417x318
Net weight (kg)
9.5

Διαθέσιμο
Κωδικός
0.502.043
Κατηγορία
Tescom UPS
Rated voltage
208 V / 220 V / 230 V / 240 Vac
Voltage range
"110 -176 Vac (linear derating between 50% and 100% load), 176 - 280 Vac (no derating), 280 - 300 Vac (derating50%)"
Frequency
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
- 25% + 15% settableTotal Harmonic Distortion (THDi) <= 6%
Voltage
208 / 220 / 230 / 240 Vac (settable via LCD)
Voltage regulation
1 +-
Frequency
45 - 55 Hz or 55 - 65 Hz (synchronized range); 50 / 60 Hz + - 0.1 Hz (battery mode)
Waveform
Sinusoidal
Power factor
0.9
Total harmonic distortion (THDv)
<= 2% (linear load), <= 5% (non-linear load
Crest factor
3:1
Overload
105% - 125% for 1 min, 125% - 150% for 30 s, > 150% for 300 ms
DC voltage
24 V (S)
Inbuilt battery
2 x 9 A
Charging current (max.)
1A
Recharge time
Standard model: 90% capacity restored in 4 hours, Long time model: depend on the capacity of battery
Efficiency
>= 90% (Mains mode), >= 85% (Battery mode), >= 95% (ECO mode)
Transfer time
Mains mode to battery mode: 0 ms, Inverter mode to bypass mode: 4 ms (typical)
Protections
Short-circuit, overload, overtemperature, battery discharge protection and fan testing protection
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP (optional)
Display
LCD + LED
Standards
EN 62040-1, EN 62040-2, EN 61000-3-2, EN 61000-3-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-2-2, IEC 62040-2, IEC 62040-1
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 50 Db
Dimensions
440 x 338 x 88
Packaged dimensions
545 x 428 x 194
Net weight (kg)
10.6
Gross weight (kg)
11.3

Διαθέσιμο
Κωδικός
0.502.041
Κατηγορία
Tescom UPS
Rated voltage
208 V / 220 V / 230 V / 240 Vac
Voltage range
110 - 176 Vac (linear derating between 50% and 100% load ), 176 - 280 Vac (no derating), 280 - 300 Vac (derating 50%)
Frequency
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
25% +15% (settable)Total Harmonic Distortion (THDi) <= 6%
Voltage
208 V / 220 V / 230 V / 240 Vac (settable via LCD)
Voltage regulation
1 +-
Waveform
Sinusoidal
Crest factor
3:01
Harmonic distortion
<= 2% (linear load); <= 5% (non-linear load)
Transfer time
Mains mode to battery mode: 0 ms, Inverter mode to bypass mode: 4 ms (typical)
Overload capability
105% - 125%: transfer to bypass in 1 min, 125% - 150%: transfer to bypass in 30 s, > 150%: transfer to bypass in 300 ms
Mains mode
>= 91%
Battery mode
>= 86%
ECO mode
>= 96%
DC voltage
48 V
Inbuilt battery
4 x 12v 9Ah
Charging current (max.)
1A
Recharge time
8 h
TYPE
VRLA sealed lead acid maintenance free
ALARMS
On Utility failure / Low battery / Overload / UPS fault
RS232 (standard) / USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows? 7 / 8 / 10
SNMP (optional)
Power management from SNMP manager and web browser
Output Power Plugs
3 Schuko (3 IEC optional)
Operating temperature
0 - 40°C
Storage temperature
from -40 to 70 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000m, derating 1% for each additional 100m
IP rating
IP20
Noise level
<= 50 dB (1m)
Dimensions
191x418x335
Packaged dimensions
318x533x471
Net weight (kg)
18

Διαθέσιμο
Κωδικός
0.502.042
Κατηγορία
Tescom UPS
Rated voltage
208 V / 220 V / 230 V / 240 Vac
Voltage range
110 - 176 Vac (linear derating between 50% and 100% load ), 176 - 280 Vac (no derating), 280 - 300 Vac (derating 50%)
Frequency
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
25% +15% (settable)Total Harmonic Distortion (THDi) <= 6%
Voltage
208 V / 220 V / 230 V / 240 Vac (settable via LCD)
Voltage regulation
1 +-
Frequency
45- 55 Hz or 55 - 65 Hz (synchronized range), 50 / 60 Hz + - 0.1 Hz (battery mode)
Waveform
Sinusoida
Crest factor
3:01
Harmonic distortion
<= 2% (linear load); <= 5% (non-linear load)
Transfer time
Mains mode to battery mode: 0 ms, Inverter mode to bypass mode: 4 ms (typical)
Overload capability
105% - 125%: transfer to bypass in 1 min, 125% - 150%: transfer to bypass in 30 s, > 150%: transfer to bypass in 300 ms
Mains mode
>= 92%
Battery mode
>= 87%
ECO mode
>= 97%
DC voltage
72 V
Inbuilt battery
6 x 12v 9Ah
Charging current (max.)
1A
Recharge time
8 h
TYPE
VRLA sealed lead acid maintenance free
ALARMS
On Utility failure / Low battery / Overload / UPS fault
RS232 (standard) / USB (optional)
Supports Windows? 98 / 2000 / 2003 / XP / Vista / 2008 / Windows? 7 / 8 / 10
SNMP (optional)
Power management from SNMP manager and web browser
Output Power Plugs
4 Schuko (6 IEC optional)
Operating temperature
0 - 40°C
Storage temperature
from -40 to 70 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000m, derating 1% for each additional 100m
IP rating
IP20
Noise level
<= 50 dB (1m)
Dimensions
191x464x335
Packaged dimensions
320x573x471
Net weight (kg)
32

Διαθέσιμο
Κωδικός
0.502.044
Κατηγορία
Tescom UPS
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
"110 -176 Vac (linear derating between 50% and 100% load), 176 - 280 Vac (no derating), 280 - 300 Vac (derating50%)"
Frequency
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
- 25% + 15% settableTotal Harmonic Distortion (THDi) <= 6%
Voltage
208 / 220 / 230 / 240 Vac (settable via LCD)
Voltage regulation
1 +-
Frequency
45 - 55 Hz or 55 - 65 Hz (synchronized range); 50 / 60 Hz + - 0.1 Hz (battery mode)
Waveform
Sinusoidal
Power factor
0.9
Total harmonic distortion (THDv)
<= 2% (linear load), <= 5% (non-linear load
Crest factor
3:1
Overload
105% - 125% for 1 min, 125% - 150% for 30 s, > 150% for 300 ms
DC voltage
48 V (S)
Inbuilt battery
4 x 9 Ah
Charging current (max.)
1A
Recharge time
Standard model: 90% capacity restored in 4 hours, Long time model: depend on the capacity of battery
Efficiency
>= 90% (Mains mode), >= 85% (Battery mode), >= 95% (ECO mode)
Transfer time
Mains mode to battery mode: 0 ms, Inverter mode to bypass mode: 4 ms (typical)
Protections
Short-circuit, overload, overtemperature, battery discharge protection and fan testing protection
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP (optional)
Display
LCD + LED
Standards
"EN 62040-1, EN 62040-2, EN 61000-3-2, EN 61000-3-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-2-2, IEC 62040-2, IEC 62040-1"
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 50 Db
Dimensions
440 x 430 x 88
Packaged dimensions
545 x 560 x 201
Net weight (kg)
18.7
Gross weight (kg)
21.8

Περιορισμένα τεμάχια
Κωδικός
0.502.045
Κατηγορία
Tescom UPS
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
"110 -176 Vac (linear derating between 50% and 100% load), 176 - 280 Vac (no derating), 280 - 300 Vac (derating50%)"
Frequency
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
- 25% + 15% settableTotal Harmonic Distortion (THDi) <= 6%
Voltage
208 / 220 / 230 / 240 Vac (settable via LCD)
Voltage regulation
1 +-
Frequency
45 - 55 Hz or 55 - 65 Hz (synchronized range); 50 / 60 Hz + - 0.1 Hz (battery mode)
Waveform
Sinusoidal
Power factor
0.9
Total harmonic distortion (THDv)
<= 2% (linear load), <= 5% (non-linear load
Crest factor
3:1
Overload
105% - 125% for 1 min, 125% - 150% for 30 s, > 150% for 300 ms
DC voltage
72 V (S)
Inbuilt battery
6 x 9 Ah
Charging current (max.)
1A
Recharge time
Standard model: 90% capacity restored in 4 hours, Long time model: depend on the capacity of battery
Efficiency
>= 92% (Mains mode), >= 87% (Battery mode), >= 97% (ECO mode)
Transfer time
Mains mode to battery mode: 0 ms, Inverter mode to bypass mode: 4 ms (typical)
Protections
Short-circuit, overload, overtemperature, battery discharge protection and fan testing protection
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP (optional)
Display
LCD + LED
Standards
"EN 62040-1, EN 62040-2, EN 61000-3-2, EN 61000-3-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-2-2, IEC 62040-2, IEC 62040-1"
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 50 Db
Dimensions
440 x 560 x 88
Packaged dimensions
545 x 690 x 201
Net weight (kg)
26.8
Gross weight (kg)
29.7

Αναμένεται
Κωδικός
0.502.121
Κατηγορία
Tescom UPS
Nomina voltage
200/208/220/230/240 VAC
Voltage range
110-300 VAC +- 5% , 50% load, 160-300 VAC +-5% ,100% load
Frequency
40Hz - 70Hz
Power factor
>=0.99 @ nominal voltage (100% load)
Harmonic Distortion(THDi)
<= 5% @ nominal input voltage
Output Voltage
200*/208*/220/230/240 VAC
Voltage regulation
1 +-
Frequency (Synchronized Range)
57 - 63 Hz or 47 - 53 Hz
Frequency Range (Batt. Mode)
50 Hz +- 0.1Hz or 60Hz +- 0.1Hz
Waveform
4 sm
Power factor
0.9
Total harmonic distortion
= 2 % THD (Linear Load), = 4 % THD (Non-linear load)
Current Crest Ratio
3:1 (max.)
Overload
110-130% : 5 min / 130-140%: 30 sec / >140% : 1.5 sec to 100ms
Outlets
8 x IEC 320 C13
Battery Type (VRLA)
2 x 12 V / 9 AH
Typical Recharge Time
3 hours recover to 95% capacity for internal battery 2A charging current
Charging current (max.)
1A
Charging Current
Default 2A, max. 12A adjustable
Charging Voltage
27.4 VDC +- 1%
Dimension
410 x 438 x 88
Net Weight (without battery) (kgs)
6,6
Net Weight (w/built-int battery) (kgs)
11,6
Humidity
5-95 % RH , 0- 40°C (non-condensing)
Noise Level
Less than 50dBA @ 1 Meter
Altitude
10% de-rating for over 1000m (The altitude should not exceed 3000m)
Smart RS-232/USB & Software
Supports Windows 2000/2003/ XP/ Vista/ 2008/ 7/ 8, Linux and MAC
Optional SNMP
Power management from SNMP manager and web browser
EMC/safety
EMC EN62040-2 C2 / EN 62040 - 1 / EN 62040 3 / RoHS 2

Αναμένεται
Κωδικός
0.502.119
Κατηγορία
Tescom UPS
Nominal Voltage
200/208/220/230/240 VAC
Voltage range
10~300VAC ± 3 % at 50% load 176~300VAC ± 3 % at 100% load
Frequency range
46~54 Hz 50Hz / 56~64 Hz 60HzPhase Single phase with ground
Power factor
>= 0.99 full loadTotal Harmonic Distortion (THDi) <4% 100% Load, <6% 50% Load
Output Voltage
200*/208*/220/230/240 VAC
AC Voltage Regulation
= +- 1%
Frequency Range
46~54 Hz 50 Hz / 56~64 Hz 60 Hz
Current Crest Ratio
3:1 max
Harmonic Distortion
<=1% THD (Linear Load), <= 4 % THD (Non-linear Load)
Transfer Time
AC mode to Battery mode= Zero, Inverter to Bypass= Zero
Waveform
Pure Sinewave
Overload
AC Mod 100%~110%: 10min / 110%~130%: 1min / >130% : 1sec, Battery Mode 100%~110%: 30sec / 110%~130%: 10sec / >130% : 1sec
AC Mode
94%
ECO Mode
98,50%
Battery Mode
92%
Battery Type (VRLA)
Depending on applications
Numbers
16-20**
Typical Recharge Time
9 hours recover to 90% capacity
Charging Current
4.0 A
Charging Voltage
(13.65VDC x battery number) +- 1%
Standard Model Dimension, D x W x H (mm)
610 x 438 x 88 [2U]
Net Weight
17 kg
Humidity
<95 % RH 0- 40 (non-condensing)
Noise Level
Less than 55dBA 1 Meter
Smart RS-232/USB & Softwarel
Supports Windows 2000/ 2003/ XP/ Vista / 2008, Windows 7/8, Linux, Unix, and MAC
Optional SNMPl
Power management from SNMP manager and web browser
EMC/safety
EMC EN62040-2 C2 / EN 62040 - 1 / EN 62040 3 / RoHS 2

Αναμένεται
Κωδικός
0.502.120
Κατηγορία
Tescom UPS
Nominal Voltage
200/208/220/230/240 VAC
Voltage range
10~300VAC ± 3 % at 50% load 176~300VAC ± 3 % at 100% load
Frequency range
46~54 Hz 50Hz / 56~64 Hz 60HzPhase Single phase with ground
Power factor
>= 0.99 full loadTotal Harmonic Distortion (THDi) <4% 100% Load, <6% 50% Load
Output Voltage
200*/208*/220/230/240 VAC
AC Voltage Regulation
= +- 1%
Frequency Range
46~54 Hz 50 Hz / 56~64 Hz 60 Hz
Current Crest Ratio
3:1 max
Harmonic Distortion
<=1% THD (Linear Load), <= 4 % THD (Non-linear Load)
Transfer Time
AC mode to Battery mode= Zero, Inverter to Bypass= Zero
Waveform
Pure Sinewave
Overload
AC Mod 100%~110%: 10min / 110%~130%: 1min / >130% : 1sec, Battery Mode 100%~110%: 30sec / 110%~130%: 10sec / >130% : 1sec
AC Mode
94%
ECO Mode
98,50%
Battery Mode
92%
Battery Type (VRLA)
Depending on applications
Numbers
16-20**
Typical Recharge Time
9 hours recover to 90% capacity
Charging Current
4.0 A
Charging Voltage
(13.65VDC x battery number) +- 1%
Standard Model Dimension, D x W x H (mm)
610 x 438 x 88 [2U]
Net Weight
17 kg
Humidity
<95 % RH @ 0- 40 (non-condensing)
Noise Level
Less than 58dB 1 Meter
Smart RS-232/USB & Softwarel
Supports Windows? 2000/ 2003/ XP/ Vista / 2008, Windows 7/8, Linux, Unix, and MAC
Optional SNMPl
Power management from SNMP manager and web browser
EMC/safety
EMC EN62040-2 C2 / EN 62040 - 1 / EN 62040 3 / RoHS 2

Αναμένεται
Κωδικός
0.502.049
Κατηγορία
Tescom UPS
Input wiring
Single-phase three-wire
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
80 - 176 Vac (linear derating between 40% and 100% load), 176 - 288 Vac (no derating)
Rated frequency
50 / 60 Hz (auto-sensing)
Frequency range
40 - 70 Hz
Power factor
>= 0.99
Bypass voltage range
(- 40%, +15%) (settable)Total Harmonic Distortion (THDi) <= 5%
Output wiring
Single-phase
Voltage rated
208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage regulation
1 +-
Frequency
Synchronized to bypass in mains mode, 50 / 60 Hz+ - 0.1% Hz in battery mode
Waveform
Sinusoidal
Power factor
1
Total harmonic distortion (THDv)
<= 1% (linear load), <= 3% (non-linear load)
Crest factor
3:01
Overload
102% - 110% for 10 min, 110% - 125% for 1 min,125% - 150% for 30 s
DC voltage
192 Vdc (192 - 240 Vdc settable) AGM VRLA and Li-On (optional)
Number of battery
16 pcs (16 ~ 20 settable)
Inbuilt battery (standard model)
(sold separately)
Charging current
12A
Recharge time
depend on the capacity of battery
Efficiency
>= 94% at 100% load, max. 94.5% at 60% load, >= 98% in ECO mode
Transfer time
0 ms
Protections
Short-circuit, overload, overtemperature, battery low voltage, overvoltage, undervoltage and fan failure
Max. number of parallel connections
4
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temperature compensation (optional)
Display
LCD + LED
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 55 dB
Dimensions
440 x 580 x 88
Packaged dimensions
514 x 696 x 168
Net weight (kg)
12
Gross weight (kg)
14

Αναμένεται
Κωδικός
0.502.046
Κατηγορία
Tescom UPS
Input wiring
Single-phase three-wire
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
110 - 176 Vac (linear derating between 50% and 100% load), 176 - 288 Vac (no derating)
Rated frequency
50 / 60 Hz (auto-sensing)
Frequency range
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
(- 40%, +15%) (settable)Total Harmonic Distortion (THDi) <= 5%
Output wiring
Single-phase three-wire
Voltage rated
208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage regulation
1 +-
Frequency
Synchronized to bypass in mains mode; 50 / 60 Hz ± 0.1% Hz in battery mode
Waveform
Sinusoidal
Power factor
1
Total harmonic distortion (THDv)
<= 1% (linear load, <= 4% (non-linear load)
Crest factor
3:1
Overload
105% - 110% for 10 min, 110% - 125% for 1 min,126% - 150% for 30 s
DC voltage
192 Vdc (192 - 240 Vdc settable)
Number of battery
16 - 20
Inbuilt battery (standard model)
12 V / 7 Ah x 16
Charging current
1A
Recharge time
Standard model: 90% capacity restored in 8 hours
Efficiency
>= 94% at 100% load, max. 95% at 60% load, >= 98% in ECO mode
Transfer time
0 ms
Protections
Short-circuit, overload, overtemperature, battery low voltage, overvoltage, undervoltage and fan failure
Max. number of parallel connections
4
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temperature compensation (optional)
Display
LCD + LED
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 55 Db
Dimensions
191 x 465 x 711
Packaged dimensions
310 x 654 x 941
Net weight (kg)
53
Gross weight (kg)
61

Αναμένεται
Κωδικός
0.502.050
Κατηγορία
Tescom UPS
Input wiring
Single-phase three-wire
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
80 - 176 Vac (linear derating between 40% and 100% load), 176 - 288 Vac (no derating)
Rated frequency
50 / 60 Hz (auto-sensing)
Frequency range
40 - 70 Hz
Power factor
>= 0.99
Bypass voltage range
(- 40%, +15%) (settable)Total Harmonic Distortion (THDi) <= 5%
Output wiring
Single-phase
Voltage rated
208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage regulation
1 +-
Frequency
Synchronized to bypass in mains mode, 50 / 60 Hz+ - 0.1% Hz in battery mode
Waveform
Sinusoidal
Power factor
1
Total harmonic distortion (THDv)
<= 1% (linear load), <= 3% (non-linear load)
Crest factor
3:01
Overload
102% - 110% for 10 min, 110% - 125% for 1 min,125% - 150% for 30 s
DC voltage
192 Vdc (192 - 240 Vdc settable) AGM VRLA and Li-On (optional)
Number of battery
16 pcs (16 ~ 20 settable)
Inbuilt battery (standard model)
(sold separately)
Charging current
12A
Recharge time
depend on the capacity of battery
Efficiency
>= 94% at 100% load, max. 94.5% at 60% load, >= 98% in ECO mode
Transfer time
0 ms
Protections
Short-circuit, overload, overtemperature, battery low voltage, overvoltage, undervoltage and fan failure
Max. number of parallel connections
4
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temperature compensation (optional)
Display
LCD + LED
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 55 dB
Dimensions
440 x 580 x 88
Packaged dimensions
514 x 696 x 168
Net weight (kg)
14
Gross weight (kg)
16

Αναμένεται
Κωδικός
0.502.047
Κατηγορία
Tescom UPS
Input wiring
Single-phase three-wire
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
110 - 176 Vac (linear derating between 50% and 100% load), 176 - 288 Vac (no derating)
Rated frequency
50 / 60 Hz (auto-sensing)
Frequency range
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
(- 40%, +15%) (settable)Total Harmonic Distortion (THDi) <= 5%
Output wiring
Single-phase three-wire
Voltage rated
208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage regulation
1 +-
Frequency
Synchronized to bypass in mains mode; 50 / 60 Hz ± 0.1% Hz in battery mode
Waveform
Sinusoidal
Power factor
1
Total harmonic distortion (THDv)
<= 1% (linear load, <= 4% (non-linear load)
Crest factor
3:1
Overload
105% - 110% for 10 min, 110% - 125% for 1 min,126% - 150% for 30 s
DC voltage
192 Vdc (192 - 240 Vdc settable)
Number of battery
16 - 20
Inbuilt battery (standard model)
12 V / 7 Ah x 16
Charging current
1A
Recharge time
Standard model: 90% capacity restored in 8 hours
Efficiency
>= 94% at 100% load, max. 95% at 60% load, >= 98% in ECO mode
Transfer time
0 ms
Protections
Short-circuit, overload, overtemperature, battery low voltage, overvoltage, undervoltage and fan failure
Max. number of parallel connections
4
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temperature compensation (optional)
Display
LCD + LED
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 55 Db
Dimensions
191 x 465 x 711
Packaged dimensions
310 x 654 x 941
Net weight (kg)
53
Gross weight (kg)
61

Αναμένεται
Κωδικός
0.502.048
Κατηγορία
Tescom UPS
Input wiring
Single-phase three-wire
Rated voltage
208 / 220 / 230 / 240 Vac
Voltage range
110 - 176 Vac (linear derating between 50% and 100% load), 176 - 288 Vac (no derating)
Rated frequency
50 / 60 Hz (auto-sensing)
Frequency range
40 - 70 Hz (auto-sense)
Power factor
>= 0.99
Bypass voltage range
(- 40%, +15%) (settable)Total Harmonic Distortion (THDi) <= 5%
Output wiring
Single-phase three-wire
Voltage rated
208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage regulation
1 +-
Frequency
Synchronized to bypass in mains mode; 50 / 60 Hz ± 0.1% Hz in battery mode
Waveform
Sinusoidal
Power factor
1
Total harmonic distortion (THDv)
<= 1% (linear load, <= 4% (non-linear load)
Crest factor
3:1
Overload
105% - 110% for 10 min, 110% - 125% for 1 min,126% - 150% for 30 s
DC voltage
192 Vdc (192 - 240 Vdc settable)
Number of battery
16 - 20
Inbuilt battery (standard model)
12 V / 9 Ah x 16
Charging current
1A
Recharge time
Standard model: 90% capacity restored in 8 hours
Efficiency
>= 94% at 100% load, max. 95% at 60% load, >= 98% in ECO mode
Transfer time
0 ms
Protections
Short-circuit, overload, overtemperature, battery low voltage, overvoltage, undervoltage and fan failure
Max. number of parallel connections
4
Communications
RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temperature compensation (optional)
Display
LCD + LED
Operating temperature
0 - 40°C
Storage temperature
from -25 to 55 °C (without batteries)
Relative Humidity
0 - 95% (non-condensing)
Altitude
<= 1000 m, derating 1% for each additional 100 m
IP rating
IP 20
Noise level at 1m
<= 58 dB
Dimensions
191 x 495 x 711
Packaged dimensions
310 x 685 x 941
Net weight (kg)
62
Gross weight (kg)
70

Αναμένεται
Κωδικός
0.502.125
Κατηγορία
Tescom UPS
Nominal Voltage
3 x 400 VAC (3Ph+N)
Voltage range
110-300 VAC 50% load 176-276 VAC 100% load
Frequency range
46~54 Hz or 56~64Hz
Power factor
>= 0.99 @ 100% load
Output Voltage
208/220/230/240VAC
AC Voltage Regulation
- + 1
Frequency Range
46~54Hz or 56~64Hz
Current Crest Ratio
3:1 (max.)
Harmonic Distortion
<= 2 % THD (Linear Load) <= 5 % THD (Non-linear Load)
Transfer Time
AC mode to Battery mode= Zero, Inverter to Bypass= Zero (when phase lock fails, <4ms interruption occurs from inverter to bypass)
Waveform
Pure Sine wave
Overload
100-110% for 60 min, 110-125% for 10 min, 125%~150% 1min, >150% immediately
AC Mode
95.5%
ECO Mode
98.5%
Battery Mode
94.5%
Battery Type
Depending on the capacity of external batteries
Internal Battery Space
N/A
Charging Current
4A (12A optional)
Charging Voltage
273 VDC + - 1% (Based on 20pcs bateries)
LCD Panel
color LCD
Full Protection
Overload, Over-temperature,Utility abnormal, UPS fault, UPS warning, battery low,etc
Battery Mode
Sounding every 4 seconds
Low Battery
Sounding every second
Overload
Sounding twice every second
Fault
Continuously sounding
Standard Model Dimension, (mm)
626x 250 x 827
Net Weight
46.5
Operation Humidity
0-95 % RH 0- 40C (non-condensing)
Noise Level
Less than 58dB 1 Meter
Smart RS-232/USB & Softwarel
Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8, Linux and MAC

Αναμένεται
Κωδικός
0.502.134
Κατηγορία
Tescom UPS
Rated Voltage
380 / 400 / 415 Vac (L-L)
Voltage range
304~478Vac (L-L), full load 228V~304Vac (L-L), load decrease linearly according to the min phase voltage
Rated frequency
50 / 60 Hz (auto-sensing)
Frequency range
40 ~ 70 Hz
Power factor
> 0.99Total Harmonic Distortion (THDi) <3% (full linear load)
Rated Voltage
380 / 400 / 415 Vac (L-L)
Voltage Regulation
= +- 1% (full linear load)
Frequency
Synchronized with utility in mains mode, 50/60 Hz ±0.1% in battery mode
Waveform
Sinusoidal
Power factor
1
Harmonic Distortion
<1% (full linear load) <3% (full non-linear load according to IEC/EN62040-3)
Current Crest Ratio
3:1
Overload
<110%, 60min, 110%~125%, 10min; 125%~150%,1min, >150%, 200ms
Bypass voltage range
Selectable, default -20%~+15% Up limited: +10%, +15%, +20%, +25%; Down limited: -10%, -15%, -20%, -30%, -40%
Bypass frequency range
Selectable, + - 1Hz, + - 3Hz, + - 5Hz
Bypass overload
125%: long term operation; 125%~130%: 10min; 130%~150%: 1min; 150%~400%: 1s; >400%, less than 200ms
DC voltage
120 ~ 240 Vdc settable
Charging current
10A Max
Recharge time
90% capacity restored in 8 hours
Charger voltage precision
1%
Inbuilt battery
N/A
Efficiency
95% Max
Transfer time
0 ms
Protections
Short-circuit, output overload, overtemperature, battery low voltage, overvoltage / undervoltage and fan failure
Max. number of parallel connections
4
Communications
RS232, USB, RS485, EPO, Dry contacts, Parallel port (Standard) SNMP card, WI-FI card, GPRS card, SMS alarms (Optional)
Display
LED + 5 inches LCD touch screen
Operating temperature
0C ~ 40C
Storage temperature
Min 40 C Under Zero ~ 70 B360C (B360without battery)
Relative humidity
0 ~ 95% (non-condensing)
Altitude
<1000m, load derated 1% per 100m from 1000 ~ 2000m
IP rating
IP 20
Noise level at 1 m
55dB 100% load, 52dB 50% load
Dimensions (mm)
250 x 720 x 560
Βρέθηκαν 36 προϊόντα
Προϊόντα 1 - 24 από 36
Οι τιμές ΔΕΝ περιλαμβάνουν τον Φ.Π.Α.
Οι Πιστοποιήσεις μας
Γιατί Ξεχωρίζουμε
ΠΕΡΙΣΣΟΤΕΡΑ
Microsoft authorized refurbisher
Microsoft surface authorized reseller
ADISA Accredited Pass
BLANCO
WEEE
ISO 27001
ISO 14001
ISO 9001
×

Αυτός ο ιστότοπος χρησιμοποιεί cookies για τη διάκριση των επισκεπτών. Για να αποδεχθείτε την τοποθέτηση cookies, επιλέξτε
Πολιτική cookies
