ModelTM-1701C
Name17 inch touch screen monitor
ColorWhole black color machine
MaterialMetal base , metal front frame with plastic back cover
VESA75*75mm for wall mounting(need extra wall mounting bracket)
OSD LanguageSupport 8kinds of international languages
Display area337.92(W)×270.336(H) mm
Pixel pitch0.264*0.264
Aspect ratio5:4
Resoluiton1280*1024
Brightness300cd/m2
Contrast1000:1
Display color16.7M
View angleHorizon: 170; Vertical :160
Response time5ms
Touch screencapacitive touch panel
StructureG+G（Cover Glass+LOCA+ITO+Glass）
Responding speed<5ms
Total light transmittance85% above
Touch life>50,000,000 times
InterfaceVGA - HDMI
Side key functionAuto, Menu,Up,Down,Power Swicth
Operating temperature0 to 40 degrees centigrade
Storage temperature-10 to 60 degrees centigrade
Working humidity10%~80% No condensation
Storage humidity10%~90% No condensation
Package with foam inside470*230*420mm/8.0kg
4 in 1 carton710*450*370mm/27kg
Power adapter110-240V/50-60HZ AC power input ,DC12V/4A output adaptor
CablePower cord compatible with USA /EU / UK etc and customized available,USB cable for touch,VGA cable(HDMI cable for option)
Touch relatedTouch pen
