Chasis 1U Rack
CPU 2 x Intel Xeon E5-2620, FCLGA2011
RAM 2 x 16GB, Up to 768 GB
RAM Slots24 DIMM sockets, DDR4
HDD Bays-
Internal Storage (max) 12 x 2.5” HDD, Up to 92 TB
On board network NIC 4p
Internal Raid Controllers M5210
PCI Slots PCIe 3.0 x16 or ML2; low profile, half-length (not present if the HDD Rear Kit is installed), PCIe 3.0 x16 or PCIe 3.0 x8; low profile or full-height, half-length (PCIe 3.0 x16 slot requires the second processor to be installed) (not present if the HDD Rear Kit is installed), PCIe 3.0 x16 or PCIe 3.0 x8; low profile, half-length, PCIe 3.0 x8 (dedicated for an internal storage controller)
USB rear 2x USB 3.0, front 1x USB 2.0 (standard), internal 1x USB 2.0
PSU 2 x 750W
