FeaturesStylish and compact design, 300,000 pixels overall situation exposure, Minimum resolution: 4 mils, Bright White LED for illuminating scanning surfaces, Read all mainstream 1D&2D bar codes, Strong body with scratch-resistant material, Quickly read various screen bar codes, Compatible with Microsoft Windows/Linux/Android/IOS/MacOS
Light SourceLED
Image sensor640*480 pixels
Resolution(maximum)0.102mm / 4mils
Print contrast ratio(minimum)≥15%
Motion tolerance2M/sec
Reading AnglePitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°
Decoding Capability1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded. 2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code. Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.
Reading IndicatorsLED/Buzzer(adjustable tone）
Typical depth of FiledPrecision Barcode Depth of Filed 5mil CODE128 0mm—70mm 5mil EAN-13 0mm—70mm 4mil EAN-13 0mm—240mm 5mil PDF417 0mm—60mm 10mil PDF417 0mm—170mm 15mil PDF417 0mm—270mm 20mil DM 0mm—80mm (The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)
Dimensions（L*W*H）96*105.55*157.06mm
Weight278g
Cable1.8M
CurrentWorking current（Standard): < 300 mA Standby current（Standard): < 210 mA
Input Voltage5 VDC (+/- 10%)/500mA
ESD protection(Air discharge)8 kV
Drop resistanceWithstands repeated drops from 1.2m/4.0 ft onto a concrete surface.
TemperatureOperation: 0 to 40 °C, Storage/Transport: -40 to 70 °C
Humidity(non-condensing)5 - 95%
Ambient light0 -100,000 lux
