Power supplyInput：AC 100V-240V, 50-60Hz, Output：DC 24V/ 2.5A
Cash drawerDC 24V/1A
Graphics printingSupports bitmap download and print (each bitmap size Max.20K)
Printer head lifespan150KM
CutterAuto cutter
BufferInput buffer256K, NV Flash 256K
OS supportingCompatible with iOS/ Android/ Windows
Safety standardsCE, FCC, Rohs etc
Printing methodDirect thermal line
Resoluiton576 Dots / Line or 512 Dots/ Line（8dots /mm, 203dpi）
Printing speed300mm/s (URL/ URL+ BT/ URL+WIFI)
Print width72mm
Graphics printingSupports bitmap download and print
Printing CommandCompatible with ESC/POS
Barcode1D barcode: UPC-A/ UPC-E/ JAN13（EAN13）/ JAN8（EAN8）/ CODE39/ ITF/CODABAR/ CODE93/ CODE128. 2D barcode: QR CODE （Single USB or UR solution no QR code function）
CharacterStandard GB18030 simplified / traditional Chinese Fonts
Character size384dots/ line, ANK character, Font: A: 12 * 24dots, 1.5(W) * 3.0(H) mm. FontB: 9*17dots, 1.1(W) * 2.1 (H)mm. Simplified/ Traditional: 24*24dots, 3.0(W) * 3.0(H)mm.
Paper typeThermal roll paper
Paper width48mm/ 52mm/ 56mm/ 64mm/ 68mm/ 76mm/ 80mm
Paper Thickness0.06~0.08mm
Paper roll diameter80mm Max
Dimensions196*145*135mm
Weight1.65kg
Working temperature& humidity0 to 45 degrees centigrade, 10%~80% No condensation
