INPUT
Nominal Voltage 3 x 400 VAC (3Ph+N)
Voltage range 110-300 VAC 50% load 176-276 VAC 100% load
Frequency range 46~54 Hz or 56~64Hz
Power factor >= 0.99 @ 100% load
OUTPUT
Output Voltage 208/220/230/240VAC
AC Voltage Regulation - + 1
Frequency Range 46~54Hz or 56~64Hz
Current Crest Ratio 3:1 (max.)
Harmonic Distortion <= 2 % THD (Linear Load) <= 5 % THD (Non-linear Load)
Transfer Time AC mode to Battery mode= Zero, Inverter to Bypass= Zero (when phase lock fails, <4ms interruption occurs from inverter to bypass)
Waveform Pure Sine wave
Overload 100-110% for 60 min, 110-125% for 10 min, 125%~150% 1min, >150% immediately
EFFICIENCY
AC Mode 95.5%
ECO Mode 98.5%
Battery Mode 94.5%
BATTERIES
Battery Type Depending on the capacity of external batteries
Internal Battery Space N/A
Charging Current 12A
Charging Voltage 273 VDC + - 1% (Based on 20pcs bateries)
IDNICATORS
LCD Panel color LCD
Protection
Full Protection Overload, Over-temperature,Utility abnormal, UPS fault, UPS warning, battery low,etc
ALARM
Battery Mode Sounding every 4 seconds
Low Battery Sounding every second
Overload Sounding twice every second
Fault Continuously sounding
PHUSICAL
Standard Model Dimension, (mm) 626x 250 x 827
Net Weight 46.5
ENVIRONMENT
Operation Humidity 0-95 % RH 0- 40C (non-condensing)
Noise Level Less than 65dB 1 Meter
MANAGMENT
Smart RS-232/USB & Softwarel Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8, Linux and MAC
