INPUT
Rated Voltage 380 / 400 / 415 Vac (L-L)
Voltage range 304~478Vac (L-L), full load 228V~304Vac (L-L), load decrease linearly according to the min phase voltage
Rated frequency 50 / 60 Hz (auto-sensing)
Frequency range 40 ~ 70 Hz
Power factor > 0.99Total Harmonic Distortion (THDi) <3% (full linear load)
OUTPUT
Rated Voltage 380 / 400 / 415 Vac (L-L)
Voltage Regulation = +- 1% (full linear load)
Frequency Synchronized with utility in mains mode, 50/60 Hz ±0.1% in battery mode
Waveform Sinusoidal
Power factor 1
Harmonic Distortion <1% (full linear load) <3% (full non-linear load according to IEC/EN62040-3)
Current Crest Ratio 3:1
Overload <110%, 60min, 110%~125%, 10min; 125%~150%,1min, >150%, 200ms
BYPASS
Bypass voltage range Selectable, default -20%~+15% Up limited: +10%, +15%, +20%, +25%; Down limited: -10%, -15%, -20%, -30%, -40%
Bypass frequency range Selectable, + - 1Hz, + - 3Hz, + - 5Hz
Bypass overload 125%: long term operation; 125%~130%: 10min; 130%~150%: 1min; 150%~400%: 1s; >400%, less than 200ms
BATTERIES
DC voltage 120 ~ 240 Vdc settable
Charging current 10A Max
Recharge time 90% capacity restored in 8 hours
Charger voltage precision 1%
Inbuilt battery N/A
SYSTEM
Efficiency 95% Max
Transfer time 0 ms
Protections Short-circuit, output overload, overtemperature, battery low voltage, overvoltage / undervoltage and fan failure
Max. number of parallel connections 4
Communications RS232, USB, RS485, EPO, Dry contacts, Parallel port (Standard) SNMP card, WI-FI card, GPRS card, SMS alarms (Optional)
Display LED + 5 inches LCD touch screen
OTHERS
Operating temperature 0C ~ 40C
Storage temperature Min 40 C Under Zero ~ 70 B360C (B360without battery)
Relative humidity 0 ~ 95% (non-condensing)
Altitude <1000m, load derated 1% per 100m from 1000 ~ 2000m
IP rating IP 20
Noise level at 1 m 55dB 100% load, 52dB 50% load
Dimensions (mm) 250 x 720 x 560
