Intel G Series Desktop PCs

HP 6200 SFF Core G Series

Available

Category: SFF
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel Q65 Express
Processors: Intel Core G Series
Memory Support: Four (4) DIMM slots , Up to 16 GB DDR3 SDRAM
Hard Drive: HDD
Removable Media: Optional
Expansion Bays: External: One (1) 3.5-inch, One (1) 5.25-inch, Internal: One (1) 3.5-inch
Expansion Slots: One (1) low-profile PCI, One (1) low-profile PCI Express x16, Two (2) low-profile PCI Express x1
Graphics: Integrated Graphics
Audio: Standard
Communications: Gigabit Ethernet
I/O Ports: 10 USB 2.0, 1 serial, 1 PS/2 keyboard, 1 PS/2 mouse, 1 DisplayPort, 1 VGA, 1 microphone/headphone jack, 1 line in, 1 line out, 1 RJ-45
Power: 240W
Dimensions: 33.8 x 37.9 x 10 cm
Weight: 7.6 kg

Limited items

Category: SFF
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel Q65
Processors: Intel Core i3,i5,i7 2nd Gen, Intel Pentium
Memory Support: Four (4) DIMM slots , Up to 16 GB DDR3
Hard Drive: Up to 1TB 7.200/10.000 rpm or SSD
Removable Media: DVD-ROM/DVD Recordable
Expansion Bays: External: One (1) 5.25-inch, One (1) 3.5-inch, Internal: Two (2) 3.5-inch
Expansion Slots: One (1) PCI-e x16, One (1) PCI-e x1 , Two (2) PCI slotm
Graphics: Intel HD Graphics
Audio: Integrated Audio, ALC662 chipset
Communications: Intel 82579 GbE Network Connection
I/O Ports: Front: Two (2) USB 2.0, microphone, Audio I/O Rear: Six (6) USB 2.0, VGA, DP, RJ-45, Audio I/O, Two (2) PS/2
Input Devices: Standard Keyboard, Mouse (USB or PS/2)
Power: 240 W
Dimensions: 44.2 cm x 41.4 cm x 17.5 cm
Weight: 7.5

Limited items

Category: Tower
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel H61 Express
Processors: Intel 2nd Generation Core i3, Intel Pentium, Intel Celeron
Memory Support: Up to 8 GB DDR3 1600 MHz SDRAM, 2 DIMM Slots
Hard Drive: HDD
Removable Media: N/A
Expansion Bays: External: One (1) 5.25-inch, Internal: One (1) 3.5-inch
Expansion Slots: One (1) PCI Express x16, Three (3) PCI Express x1, One (1) Mini PCI
Graphics: Integrated graphics (Intel HD, Intel HD 2000, Intel HD 3000, Intel HD 4000) based on processor
Audio: Realtek ALC656
Communications: Integrated Realtek RTL8171E Gigabit Ethernet Controller
I/O Ports: Front: (2) USB 2.0 ports, dedicated headphone port, microphone jack, Rear: Four (4) USB 2.0 ports, RJ-45 Ethernet Port, DVI-D and VGA video ports, audio in/out jacks (5.1 channel audio out)
Power: 300 W
Dimensions: 16.5 x 38.9 x 36.8 cm
Weight: 6.932 kg to 7.18 kg (approximate)

Available

Category: USFF - USDT
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: N/A
Processors: Intel Celeron Processor N3000 Series or Intel Pentium Processor N3000 Series
Memory Support: 1 SO-DIMM slot, 8GB max / DDR3 Low Voltage, DDR3L-1600socket
Hard Drive: M.2 SSD
Removable Media: N/A
Expansion Bays: N/A
Expansion Slots: N/A
Graphics: Intel HD Graphics in processor
Audio: Integrated Audio
Communications: 1 Gigabit Ethernet , Bluetooth 4.1
I/O Ports: Front: Two (2) USB 3.0, Audio I/O Rear: Two (2) USB 3.0, Two (2) USB 2.0 Two (2) DP, RJ-45, Audio I/O
Power: 65 W
Dimensions: 179mm X 182.9mm X 34.5mm
Weight: 1.3 kg

Limited items

Category: SFF
Operating System: Windows 10 Home & Pro MAR
Chipset: Intel Q270
Processors: Intel 6th & 7th Gen Core i3, i5, i7, Intel Pentium G, Intel Celeron G
Memory Support: Four (4) SODIMM slots , Up to 64 GB DDR4-2400
Hard Drive: SATA 7200 rpm or SSD, PCIe NMVe TLC SSD
Removable Media: HP 9.5 mm, G3 600 SFF DVD-Writer or HP 9.5 mm, G3 600 SFF DVD-ROM
Expansion Bays: Internal: One (1) 2.5-inch, One (1) 3.5-inch, External: One (1) slim ODD, One (1) SD Card Reader
Expansion Slots: One (1) Turbo Drive M.2 PCIe x1-2230, One (1) Turbo Drive M.2 PCIe x4-2280, Two (2) PCI Express x16 (v3.0); 1 wired as an x4
Graphics: Intel HD Graphics
Audio: Conexant CX20632 codec
Communications: Realtek RTL8201N FtE
I/O Ports: Front: Two (2) USB 2.0, Two (2) USB 3.1, One (1) USB Type C 3.1Audio I/O, Rear: Four (4) USB 3.1, Two (2) USB 2.0 Audio I/O, Two (2) DP, RJ-45
Input Devices: Standard Keyboard (USB)
Power: 80 PLUS Bronze 180W active PFC or 80 PLUS Platinum 180W active PFC
Dimensions: 269.24 x 93.98 x 297.18 mm
Weight: 4.53 kg

Limited items

Category: SFF
Operating System: Windows 10 Home & Pro MAR
Chipset: Intel B360
Processors: Intel 8th Gen Core i3, i5, i7, Intel Pentium G, Intel Celeron G
Memory Support: Two (2) DIMM slots , Up to 32 GB DDR4-2666 SDRAM
Hard Drive: SATA 7200 rpm or SSD, M2 SSD
Removable Media: Optional DVD
Expansion Bays: 1 slim ODD, One 3.5" HDD convertible to two 2.5" HDD
Expansion Slots: 1 M.2 2230, 1 M.2 2230/2280, 1 PCIe 3 x1, 1 PCIe 3 x16, One 4-in-1 media card reader (1 M.2 slot for WLAN and 1 M.2 2230/2280 slot for storage.)
Graphics: Intel HD Graphics 630/610
Audio: Conexant CX20632 codec
Communications: 1 Gigabit
I/O Ports: Front: 1 headset connector, 2 USB 3.1 Gen 1, Rear: 1 audio-in, 1 audio-out, 1 DisplayPort 1.2, 1 power connector, 1 RJ-45; 1 VGA, 2 USB 3.1 Gen 1, 4 USB 2.0, (optional Serial)
Power: 180 W
Dimensions: 27 x 29.6 x 9.5 cm
Weight: 4.6 kg

Available

Category: SFF
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel 630
Processors: Intel Pentium G Series, Intel Celeron, Intel Core i3, i5, i7 8th & 9th Gen
Memory Support: Up to 64GB DDR4, Four DDR4 DIMM slots, dual-channel capable
Hard Drive: SATA, SSD
Graphics: Intel UHD Graphics 610/630
Audio: Realtek ALC233VB2 codec
Communications: Integrated 100/1000M
I/O Front Ports: 2x USB 3.1 Gen 1, 2x USB 3.1 Gen 2, 1x USB-C? 3.1 Gen 1, 1x headphone / microphone combo jack (3.5mm), 1x microphone
I/O Rear Ports: 4x USB 2.0, 1x VGA, 2x DisplayPort, 1x serial (9-pin), 1x Ethernet (RJ-45)
Power: 180W or 210W or 260W
Dimensions: 92.5 x 290.5 x 343.5 mm
Weight: Around 6.0 kg

Limited items

Category: USFF - USDT
Operating System: Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset: Intel Gemini Lake
Processors: Intel Gemini Lake Pentium Quad Core
Memory Support: Two (2) SODIMM slots, up to 8GB DDR4 SODIMM (2133/2400 MHz)
Hard Drive: SATA SSD M.2
Removable Media: N/A
Expansion Bays: N/A
Expansion Slots: RJ45/SFP/VGA, PCIe slot
Graphics: Intel UHD Graphics 605
Audio: Realtek ALC3253 and Intel
Communications: 10/100/1000 Mb/s Ethernet
I/O Ports: 7 x USB ports (three front, four rear), 1 x USB Type-C port,1 x RJ45, 2 x headset/mic combo jacks, 1 x headphone jack, 2 x DP, 1 x DP without audio
Power: 130 W
Dimensions: 18.4 cm x 18.4 cm x 6.6 cm
Weight: 1.47 kg
