INPUT
Input wiring Single-phase three-wire
Rated voltage 208 / 220 / 230 / 240 Vac
Voltage range 80 - 176 Vac (linear derating between 40% and 100% load), 176 - 288 Vac (no derating)
Rated frequency 50 / 60 Hz (auto-sensing)
Frequency range 40 - 70 Hz
Power factor >= 0.99
Bypass voltage range (- 40%, +15%) (settable)Total Harmonic Distortion (THDi) <= 5%
OUTPUT
Output wiring Single-phase
Voltage rated 208 (PF=0.9) / 220 / 230 / 240 Vac
Voltage regulation 1 +-
Frequency Synchronized to bypass in mains mode, 50 / 60 Hz+ - 0.1% Hz in battery mode
Waveform Sinusoidal
Power factor 1
Total harmonic distortion (THDv) <= 1% (linear load), <= 3% (non-linear load)
Crest factor 3:01
Overload 102% - 110% for 10 min, 110% - 125% for 1 min,125% - 150% for 30 s
BATTERIES
DC voltage 192 Vdc (192 - 240 Vdc settable) AGM VRLA and Li-On (optional)
Number of battery 16 pcs (16 ~ 20 settable)
Inbuilt battery (standard model) (sold separately)
Charging current 12A
Recharge time depend on the capacity of battery
SYSTEM
Efficiency >= 94% at 100% load, max. 94.5% at 60% load, >= 98% in ECO mode
Transfer time 0 ms
Protections Short-circuit, overload, overtemperature, battery low voltage, overvoltage, undervoltage and fan failure
Max. number of parallel connections 4
Communications RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temperature compensation (optional)
Display LCD + LED
OTHER SPECS
Operating temperature 0 - 40°C
Storage temperature from -25 to 55 °C (without batteries)
Relative Humidity 0 - 95% (non-condensing)
Altitude <= 1000 m, derating 1% for each additional 100 m
IP rating IP 20
Noise level at 1m <= 55 dB
Dimensions 440 x 580 x 88
Packaged dimensions 514 x 696 x 168
Net weight (kg) 12
Gross weight (kg) 14
