Operating System Windows 10 Home & Pro MAR, Ubuntu Linux, Free DOS
Chipset Intel® C236 Chipset
Processors Intel® Xeon? Processor E3-1200 v5 Family; 6th generation Intel® Core i7, i5 and i3
Memory Support 4 Dimm Slots; Up to 64GB 2133Mhz Non-ECC DDR4 Memory; Up to 64GB 2133Mhz ECC DDR4 Memory
Hard Drive Support for up to (1) M.2 PCIe SSD on motherboard slot and Up to (2) 3.5" SATA or (4) 2.5" SATA
Removable Media N/A
Expansion Bays (2) internal 3.5" bays - supports (2) 3.5" or (4) 2.5" drives; (2) external 5.25" optical bays
Expansion Slots (1) Full Height PCIe x16 Gen3; (1) Full Height PCIe x16 Gen 3 (wired x4); (1) Full Height PCIe x4 Gen3; (1) Full Height PCI; (1) M.2 (22x80 mm)
Graphics One PCI Express? x16 Gen 3 Graphics card up to 150W (Total for Graphics)
Audio Integrated Realtek ALC3861 High Definition Audio Codec
Communications Intel Ethernet Connection I219-LM 10/100/1000
I/O Ports Front: Two USB 2.0, two USB 3.0, Mic/Headphone; Rear: Two USB 2.0, Four USB 3.0, One Serial, Two PS2, Two DisplayPort, One HDMI, One RJ-45
Input Devices USB: Dell QuietKey, Enhanced Multimedia, Smartcard Reader keyboard; Bluetooth Keyboard and Mouse, USB: Dell two-button mechanical with scroll, Dell two-button optical with scroll
Power 80 Plus Gold Certified, 90% efficient): 635W or 425W
Dimensions 36cm x 17.5cm x 43.5cm
Weight N/A
